PY Union Y Pneumatic Fitting
The PY Union Y Pneumatic Fitting offers efficient Y-style branching for PU or nylon tubes. With a push-to-connect design, 160N stainless steel clip, and NBR seal, it ensures leak-free, high-pressure performance. Ideal for space-saving installations requiring smooth airflow division without disconnection risk.
| Parameter | Value |
|---|---|
| Product Name | PY Union Y Pneumatic Fitting |
| Fitting Type | Y-Shape Push-to-Connect Branch |
| Compatible Tubing | PU Tube / Nylon Tube |
| Branch Design | Equal Diameter Y-Shape |
| Seal Material | NBR Rubber O-Ring |
| Clamp Material | Stainless Steel (160N Clamping Force) |
| Working Pressure | Up to 1.0 MPa (10 kgf/cm²) |
| Max Holding Pressure | 1.2 MPa (12 kgf/cm²) |
| Operating Temperature | 0~60°C |
| Application | Air Line Splitting in Industrial Pneumatic Systems |
